SQJ941EP
www.vishay.com
SPECIFICATIONS (T C = 25 °C, unless otherwise noted)
Vishay Siliconix
PARAMETER
SYMBOL
TEST CONDITIONS
MIN.
TYP.
MAX.
UNIT
Static
Drain-Source Breakdown Voltage
Gate-Source Threshold Voltage
Gate-Source Leakage
V DS
V GS(th)
I GSS
V GS = 0, I D = - 250 μA
V DS = V GS , I D = - 250 μA
V DS = 0 V, V GS = ± 20 V
V GS = 0 V
V DS = - 30 V
- 30
- 1.5
-
-
-
- 2.0
-
-
-
- 2.5
± 100
-1
V
nA
Zero Gate Voltage Drain Current
I DSS
V GS = 0 V
V DS = - 30 V, T J = 125 °C
-
-
- 50
μA
V GS = 0 V
V DS = - 30 V, T J = 175 °C
-
-
- 150
On-State Drain Current a
I D(on)
V GS = - 10 V
V DS = - 5 V
- 24
-
-
A
V GS = - 10 V
I D = - 9 A
-
0.020
0.024
Drain-Source On-State Resistance a
R DS(on)
V GS = - 10 V
V GS = - 10 V
I D = - 9 A, T J = 125 °C
I D = - 9 A, T J = 175 °C
-
-
0.028
0.032
0.034
0.039
?
V GS = - 4.5 V
I D = - 5 A
-
0.032
0.039
Forward Transconductance b
g fs
V DS = - 15 V, I D = - 2.5 A
-
10
-
S
Dynamic b
Input Capacitance
C iss
-
1500
1800
Output Capacitance
C oss
V GS = 0 V
V DS = - 10 V, f = 1 MHz
-
370
445
pF
Reverse Transfer Capacitance
Total Gate Charge c
C rss
Q g
-
-
260
35
315
55
Gate-Source
Charge c
Q gs
V GS = - 10 V
V DS = - 15 V, I D = - 9 A
-
4.6
-
nC
Gate-Drain Charge c
Q gd
-
8.1
-
Gate Resistance
Time c
Turn-On Delay
R g
t d(on)
f = 1 MHz
2.8
-
5.95
49
9.5
60
?
Rise Time c
Turn-Off Delay
Time c
t r
t d(off)
V DD = - 15 V, R L = 1.66 ?
I D ? - 9 A, V GEN = - 10 V, R g = 6 ?
-
-
35
47
50
60
ns
Fall Time c
t f
-
26
33
Source-Drain Diode Ratings and Characteristics b
Pulsed Current a
I SM
-
-
- 32
A
Forward Voltage
V SD
I F = - 2.5 A, V GS = 0
-
- 0.8
- 1.2
V
Notes
a. Pulse test; pulse width ? 300 μs, duty cycle ? 2 %.
b. Guaranteed by design, not subject to production testing.
c. Independent of operating temperature.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation
of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum
rating conditions for extended periods may affect device reliability. ?
S12-1848-Rev. C, 30-Jul-12
2
Document Number: 65546
For technical questions, contact: automostechsupport@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
